Description
The PyroShot FBS-1 is an innovative, labor-saving device that replaces the need for operators to carry a traditional, open-flame drip torch into hazardous or inaccessible terrain. Field-proven and durable, it uses a simple, manual slide action to automatically charge and launch incendiary “Dragon Egg” spheres. Organizations that have field-tested the FBS-1 have frequently returned to order more, confirming its value in wildfire burnout and backfire operations. By enabling operators to ignite areas like ditches, canals, bogs, briars, and steep drainages from a safe distance, the FBS-1 significantly increases safety and operational efficiency.
Key Features & Benefits
- Remote Ignition: Launch an ignition point up to 75 feet (23m) away, covering a 150-foot swath in a single pass.
- Enhanced Safety: The lack of an open flame during operation or transport means it can be used safely in areas where a drip torch would present a hazard.
- Durable Construction: All aluminum parts feature a Hard Coat Anodized finish, and all hardware is Stainless Steel to reduce maintenance and increase longevity in rugged field conditions.
- Consistent Performance: A mechanically operated displacement pump ensures precise 0.5 cc glycol delivery for super reliable ignition every time.
- Adjustable Control: A rotating butt plate allows the operator to preset spring tension, providing control over both the launch range and the required cocking effort.
- High Capacity: The onboard 250 cc glycol bottle can charge approximately 450 spheres, ensuring extended operation without frequent refilling.
- Low Operating Cost: At approximately 25 cents per round, the FBS-1 is significantly more cost-effective than traditional flares for large-scale operations.
- Simple Maintenance: Designed for ease of care with simple soap and water cleanup and light lubrication providing years of trouble-free service.
How It Works
The FBS-1 operates via a straightforward, manual two-stroke cycle:
The FBS-1 operates via a straightforward, manual two-stroke cycle:
- Cocking & Loading: The operator pulls the slide to the rear while placing the butt against their hip. This action cocks the internal spring and feeds one Dragon Egg sphere into the barrel.
- Charging & Launching: On the forward (return) stroke, a needle pierces the sphere and the pump injects the precise amount of glycol reactant. The spring releases automatically at the end of this forward stroke, launching the charged sphere to the desired location.
- Delayed Ignition: A reliable delay of 20 to 60 seconds (dependent on ambient temperature) occurs before the sphere ignites upon landing, allowing ample time for the operator to move or adjust position.
